Specifications
General
Series Name
800
Type
Built-In
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Place Settings
16
Tub Material
Stainless Steel
Silence Rating
45 dB
Cycle Information
Number of Cycles
5
Wash Cycles
• Auto Sense
• Heavy Wash
• Light Wash
• Normal Wash
• Rinse
• Heavy Wash
• Light Wash
• Normal Wash
• Rinse
Options
• Bottle Wash
• Delay Start 1-12 Hr.
• Heated Dry
• Pre Soak
• Sani (NSF Certified)
• Start/Reset
• Wash TempBoost
• Wash Zone Lower Only
• Wash Zone Upper Only
• Delay Start 1-12 Hr.
• Heated Dry
• Pre Soak
• Sani (NSF Certified)
• Start/Reset
• Wash TempBoost
• Wash Zone Lower Only
• Wash Zone Upper Only
Features
Technologies
Piranha™ Hard Food Disposer with Removable Filter
Delay Start Information
1 to 12 Hours
Delay Start
Yes
Control Lock
Yes
Filtration System
Yes
Silverware Basket
Yes
Additional Information
• Tall Tub
• 1 "Clean" Light, 1 "Sanitized" Light, 1 "Low Rinse Aid" Light
• Audible End-of-Cycle Signal
• Cycle Countdown with Bi-Color LED Status Light on door
• Last Cycle Memory
• 3-Level Wash System
• 140+ Spray Jet Wash System
• Automatic HotStart
• Automatic Temperature Control
• Deep Clean Silverware Jets
• Drain Pump
• Quad Blade Middle Wash Arm
• Reversing Quad Blade Lower Wash Arm
• Clean Sensor
• Wash Arms: 3 Wash Levels, Bottle Jets, Jets - Variable Pressure, Lower Reversing Quad Blade, Middle Quad Blade, Side Jets
• Electronic Low Rinse Aid Sensor
• 2 Utility Shelves with Stem Safe - Upper
• Adjustable Upper Rack
• Ball-Tipped Tines
• Upper Rack:1 Rack handle, 1/2 fixed tines, 1/2 fold down tines, 2 Stem Safe Shelves, Ball-Tip Tines, Premium Height Adjustable
• Lower Rack:1 Rack handle, Ball-Tip Tines, Multi-Position Fold Down Tines
• Floor Protect
• 1 "Clean" Light, 1 "Sanitized" Light, 1 "Low Rinse Aid" Light
• Audible End-of-Cycle Signal
• Cycle Countdown with Bi-Color LED Status Light on door
• Last Cycle Memory
• 3-Level Wash System
• 140+ Spray Jet Wash System
• Automatic HotStart
• Automatic Temperature Control
• Deep Clean Silverware Jets
• Drain Pump
• Quad Blade Middle Wash Arm
• Reversing Quad Blade Lower Wash Arm
• Clean Sensor
• Wash Arms: 3 Wash Levels, Bottle Jets, Jets - Variable Pressure, Lower Reversing Quad Blade, Middle Quad Blade, Side Jets
• Electronic Low Rinse Aid Sensor
• 2 Utility Shelves with Stem Safe - Upper
• Adjustable Upper Rack
• Ball-Tipped Tines
• Upper Rack:1 Rack handle, 1/2 fixed tines, 1/2 fold down tines, 2 Stem Safe Shelves, Ball-Tip Tines, Premium Height Adjustable
• Lower Rack:1 Rack handle, Ball-Tip Tines, Multi-Position Fold Down Tines
• Floor Protect
Electrical Information
Information
• 120 V
• 60 Hz
• 7.2 A
• 60 Hz
• 7.2 A
Certifications and Approvals
Energy Star Certified
Yes
NSF® Certified
Yes
Accessories
Optional
• GPFCORD
• WX09X70910
• WX09X70911
• WX09X70910
• WX09X70911
Dimensions
Class Width
24"
Width
23.75 inch(es) / 60.33 cm
Height (Min.)
33.37 inch(es) / 84.77 cm
Depth (Without Handle)
24 inch(es) / 60.96 cm
Weight
105.01 lb(s) / 47.63 kg
Additional Dimensions
Height with Legs Extended Maximum Height: 34 5/8"
Shipping Dimensions
Weight
142 lb(s) / 64.41 kg
Warranty
Warranty
Limited 1 Year Parts and Labor
